9600 baud
8 data bits
1 stop bit
No parity
None (flow control)
Step 5
Power on the switch as described in the switch getting started guide.
Step 6
The PC or terminal displays the bootloader sequence. Press Enter to display the setup prompt. Follow the
steps in the Setup program.
Installing the Cisco Microsoft Windows USB Device Driver
A USB device driver must be installed the first time a Microsoft Windows-based PC is connected to the USB
console port on the switch.
Installing the Cisco Microsoft Windows XP USB Driver
Installing the Cisco Microsoft Windows 2000 USB Driver
Installing the Cisco Microsoft Windows Vista and Windows 7 USB Driver
Installing the Cisco Microsoft Windows XP USB Driver
Procedure
Step 1
Obtain the Cisco USB console driver file from the Cisco.com web site and unzip it.
You can download the driver file from the Cisco.com site for downloading the switch software.Note
Step 2
If using 32-bit Windows XP, double-click the setup.exe file in the Windows_32 folder. If using 64-bit Windows
XP, double-click the setup(x64).exe file in the Windows_64 folder.
Step 3
The Cisco Virtual Com InstallShield Wizard begins.
Step 4
The Ready to Install the Program window appears. Click Install.
Step 5
The InstallShield Wizard Completed window appears. Click Finish.
Step 6
Connect the USB cable to the PC and the switch console port. The USB console port LED turns green, and
the Found New Hardware Wizard appears. Follow the instructions to complete the driver installation.
Catalyst 2960-X and 2960-XR Switch Hardware Installation Guide
86 OL-28309-02
Configuring the Switch with the CLI-Based Setup Program
Installing the Cisco Microsoft Windows USB Device Driver

Table of Contents

Other manuals for Cisco Catalyst 2960-X

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco Catalyst 2960-X and is the answer not in the manual?

Cisco Catalyst 2960-X Specifications

General IconGeneral
Console portRJ-45
USB 2.0 ports quantity2
SFP module slots quantity4
Installed SFP modules quantity-
Gigabit Ethernet (copper) ports quantity48
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Power sourceAC
Input current5 A
AC input voltage100 - 240 V
Power consumption (typical)60.9 W
Number of power supply units1
Redundant power supply (RPS) supportYes
Operating altitude0 - 3000 m
Non-operating altitude0 - 4000 m
Storage temperature (T-T)-25 - 70 °C
Operating temperature (T-T)-5 - 40 °C
Operating relative humidity (H-H)10 - 95 %
Switching protocolsUDP, TCP, RADIUS/TACACS+
Number of VLANs1023
Networking standardsIEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput107.1 Mpps
Jumbo frames9216
Number of queues8
MAC address table16000 entries
Number of static routes1000
DHCP featuresDHCP server
AuthenticationMAC-based authentication, Port-based authentication
Security algorithms802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules3
Switch typeManaged
Switch layerL2/L3
SafetyUL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor1U
Product colorBlack
Total Power over Ethernet (PoE) budget370 W
Power over Ethernet (PoE) ports quantity24
Power over Ethernet plus (PoE+) ports quantity12
Memory typeDRAM
Noise level39 dB
Flash memory128 MB
Internal memory512 MB
Processor frequency600 MHz
Mean time between failures (MTBF)276870 h
Weight and Dimensions IconWeight and Dimensions
Depth368 mm
Width445 mm
Height45 mm
Weight5800 g
