Uplink Interface Connectivity
LAN Access Switch Topology with Uplinks to a Distribution Switch or Distribution Router
44
Best Practice User Guide for the Catalyst 3850 and Catalyst 3650 Switch Series
Figure 7 Uplinks for a Distribution Router
Dual redundant
routers running
HSRP
Desktop user
direct connect
Desktop user
behind IP phone
Printer
Wireless access
Catalyst 3850 stack in access
Voice VLAN 11
Data VLAN 10
Data VLAN 10
Data VLAN 10
Switch management
VLAN 100
Access point VLAN 12
391936
Trunk link
Native VLAN 999
All VLANs included
