Access Control on the Wired Network
Identify Configuration Values
66
Best Practice User Guide for the Catalyst 3850 and Catalyst 3650 Switch Series
We recommend that you identify certain switch configuration values in advance so that you can proceed
without interruption. We recommend that you take a print out of Table 7, and, as you follow the
configuration sequence, replace the values in column B with your values in column C.
Note Depending on your authentication server settings, the authentication and accounting ports could be
assigned the values 1812 and 1813 respectively.
Note Replace the blue italicized example values with your own values.
Note Configuration examples begin in global configuration mode, unless noted otherwise.
Table 7 Secure Access Control for Wired Network Values
A. Value Name B. Example Value Names C. Your Value
Interface range
GigabitEthernet
1/0/1-1/0/24
RADIUS server
AuthServer
RADIUS server IPv4 address
192.168.254.14
Auth-port
1656
Acct-port
1646
RADIUS server encryption key
cisco123
Data VLAN
10
Voice VLAN
11
Auth-server dead vlan
20
Extended IP ACL
LowImpactSecurity-acl

Cisco Catalyst 3650 Specifications

General

Switching Capacity	160 Gbps
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Device Type	Switch
Form Factor	Rack-mountable
Layer	Layer 3
DRAM	4 GB
Flash Memory	4 GB
Operating System	Cisco IOS XE
Model	Catalyst 3650
Ports	24 or 48 10/100/1000 Ethernet ports
Stacking	Yes
Power over Ethernet (PoE)	Yes
Power Supply Options	350W AC
VLANs	4094
