Cisco Catalyst 3850 Guide

Converged Wired and Wireless Access
Provisioning a Small Branch WLAN
97
Best Practice User Guide for the Catalyst 3850 and Catalyst 3650 Switch Series
Step 2 Enable wireless spectrums.
The lightweight access points support two wireless spectrums: 5 Ghz and 2.4 Ghz. You must enable and
disable speeds in each spectrum, but the speeds do not have to match.
• Enable IEEE 802.11n and IEEE 802.11ac for the 5-Ghz spectrum.
• Enable IEEE 802.11n and IEEE 802.11g for the 2.4-Ghz spectrum.
Note Beacons are sent at the lowest mandatory rate that define the cell size.
When deploying the switch in converged access mode as a hotspot, the lowest data rate should be enabled
to increase coverage gain versus speed. In addition, the recommended data rates are to be used in a
wireless network with good radio frequency coverage. Data rates are contingent upon the nature of your
radio frequency deployment.
Enable Clean Air
Step 3 Enable Clean Air on the switch and on devices that are common in your deployment environment.
The switch detects and reduces radio frequency interference when Clean Air is enabled. Some sources
of interference are jammers, microwave ovens, and bluetooth devices.
.
!Enable 802.11n and 802.11g for the 2.4Ghz spectrum.
!
ap dot11 24ghz dot11g
ap dot11 24ghz dot11n
ap dot11 24ghz rate RATE_24M mandatory
ap dot11 24ghz rate RATE_1M disable
ap dot11 24ghz rate RATE_2M disable
ap dot11 24ghz rate RATE_5_5M disable
ap dot11 24ghz rate RATE_6M disable
ap dot11 24ghz rate RATE_9M disable
ap dot11 24ghz rate RATE_11M disable
ap dot11 24ghz rate RATE_12M mandatory
ap dot11 24ghz rate RATE_18M supported
ap dot11 24ghz rate RATE_36M supported
ap dot11 24ghz rate RATE_48M supported
ap dot11 24ghz rate RATE_54M supported
no ap dot11 24ghz shutdown
ap dot11 24ghz cleanair
ap dot11 5ghz cleanair
ap dot11 24ghz cleanair device jammer
ap dot11 24ghz cleanair device cont-tx
ap dot11 24ghz cleanair device dect-like
ap dot11 24ghz cleanair device mw-oven
ap dot11 24ghz cleanair device video
!
ap dot11 5ghz cleanair device jammer
ap dot11 5ghz cleanair device cont-tx
ap dot11 5ghz cleanair device dect-like
ap dot11 5ghz cleanair device video

Cisco Catalyst 3850 Specifications

General

Stacking Bandwidth	480 Gbps
Max Stacking Units	9
Form Factor	Rack-mountable
RAM	4 GB
Flash Memory	4 GB
Operating System	Cisco IOS XE
Model	Catalyst 3850
Ports	24 or 48 Gigabit Ethernet ports
Uplink Interfaces	4 x 1GE, 2 x 10GE, or 4 x 10GE
Power Supply	Redundant power supplies
Dimensions	44.5 x 44.8 x 4.45 cm
Weight	7.6 kg
Features	IPv6
Power over Ethernet (PoE)	PoE, PoE+, UPOE (varies by model)
Operating Temperature	0 to 40°C
