Cisco Catalyst 3850 Guide

Converged Wired and Wireless Access
Show Running Configuration for Wireless LAN Converged Access
100
Best Practice User Guide for the Catalyst 3850 and Catalyst 3650 Switch Series
show running configuration
ip arp inspection vlan 10-11,100
!
ip device tracking
ip snooping vlan 10-13,100,200
no ip snooping information option
ip snooping wireless bootp-broadcast enable
!
! the default router for subnet 192.168.12.x /24 is the upstream router
! 192.168.12.2 is the layer 3 address of the 3850 vlan interface on vlan 12
!
ip excluded-address 192.168.12.1
ip excluded-address 192.168.12.2
!
!
!Access Point IP pool defined locally on the 3850
!
ip pool APVlan12-pool
network 192.168.12.0 255.255.255.0
default-router 192.168.12.1
!
! Vlan 200 for wireless clients, and the subnet 192.168.13.x /23
! the server is external to the 3850.
vlan 200
name Wireless_Client
!
<snip>
!
! remember to exclude 192.168.13.2 on the server. Its statically defined
on the vlan 200 intf
interface Vlan200
description wireless Clients
ip address 192.168.13.2 255.255.255.0
!
wireless mobility controller
wireless management interface Vlan12
!
! this is copied from the “show run” output.
wlan OPEN_WLAN 1 WiFi_Open
client vlan 200
no security wpa
no security wpa akm dot1x
no security wpa wpa2
no security wpa wpa2 ciphers aes
no shutdown
!

Cisco Catalyst 3850 Specifications

General

Stacking Bandwidth	480 Gbps
Max Stacking Units	9
Form Factor	Rack-mountable
RAM	4 GB
Flash Memory	4 GB
Operating System	Cisco IOS XE
Model	Catalyst 3850
Ports	24 or 48 Gigabit Ethernet ports
Uplink Interfaces	4 x 1GE, 2 x 10GE, or 4 x 10GE
Power Supply	Redundant power supplies
Dimensions	44.5 x 44.8 x 4.45 cm
Weight	7.6 kg
Features	IPv6
Power over Ethernet (PoE)	PoE, PoE+, UPOE (varies by model)
Operating Temperature	0 to 40°C
