Access Control on the Wired Network
Monitoring IEEE 802.1x Status and Statistics
77
Best Practice User Guide for the Catalyst 3850 and Catalyst 3650 Switch Series
To detect errors, filter the dot1x verbose messages that are enabled by default.
Step 2 Use the show dot1x interface statistics command to display IEEE 802.1x statistics for a specific port.
Step 3 Use the show dot1x all command to display the IEEE 802.1x administrative and operational status for
a switch.
.
show dot1x statistics
Dot1x Global Statistics for
--------------------------------------------
RxStart = 7 RxLogoff = 0 RxResp = 0 RxRespID = 8
RxReq = 0 RxInvalid = 0 RxLenErr = 0
RxTotal = 29
TxStart = 0 TxLogoff = 0 TxResp = 0
TxReq = 0 ReTxReq = 0 ReTxReqFail = 0
TxReqID = 8 ReTxReqID = 0 ReTxReqIDFail = 0
TxTotal = 8
show dot1x interface g1/0/1 statistics
Dot1x Authenticator Port Statistics for GigabitEthernet1/0/1
--------------------------------------------
RxStart = 10 RxLogoff = 0 RxResp = 0 RxRespID = 10
RxInvalid = 0 RxLenErr = 0 RxTotal = 37
TxReq = 0 TxReqID = 11 TxTotal = 11
RxVersion = 1 LastRxSrcMAC = 0023.33db.e970
show dot1x all
Sysauthcontrol Enabled
Dot1x Protocol Version 3
Dot1x Info for GigabitEthernet1/0/1
-----------------------------------
PAE = AUTHENTICATOR
QuietPeriod = 60
ServerTimeout = 0
SuppTimeout = 30
ReAuthMax = 2
MaxReq = 2
TxPeriod = 30

Cisco Catalyst 3850 Specifications

General

Stacking Bandwidth	480 Gbps
Max Stacking Units	9
Form Factor	Rack-mountable
RAM	4 GB
Flash Memory	4 GB
Operating System	Cisco IOS XE
Model	Catalyst 3850
Ports	24 or 48 Gigabit Ethernet ports
Uplink Interfaces	4 x 1GE, 2 x 10GE, or 4 x 10GE
Power Supply	Redundant power supplies
Dimensions	44.5 x 44.8 x 4.45 cm
Weight	7.6 kg
Features	IPv6
Power over Ethernet (PoE)	PoE, PoE+, UPOE (varies by model)
Operating Temperature	0 to 40°C
