Finding Serial Numbers, on page 106
Supervisor Engine
The switch supports these Supervisor Engine 2T models:
VS-S2T-10G
VS-S2T-10G-XL
The term supervisor engine is used to refer to Supervisor Engine 2T.Note
The following requirements apply to the supervisor engines installed on the switch:
Install a 3000 W or higher-capacity power supply.
Install supervisor engines only in slot 3 or 4.
If the slots are not occupied by supervisor engines, you can install service modules. However, you cannot
install Ethernet modules in slot 3 and 4. Check your software release notes for any restrictions on the
type of module that can be installed.
In systems with redundant supervisor engines, both the supervisor engines must be of the same model
and have the same daughter card configurations.
Each supervisor engine must have the resources to run the switch on its own, which means that all the
supervisor engine resources are duplicated. Identical supervisor engine memory configurations are
recommended, but are not required, as long as the supervisor engine with the smaller memory
configuration is sufficient to run the configured features of the switch. Additionally, each supervisor
engine must have its own flash device and console port connections.
The uplink ports are fully functional on all redundant supervisor engine models when they are in the standby
mode. For more information, see the Catalyst 6500 Series Switch Module Installation Note and the "Supervisor
Engine 2T" section in the Catalyst 6500 Series Switch Supervisor Engine Guide.
Related Topics
Connecting the Supervisor Engine Console Port , on page 46
Modules
The switch supports the following Cisco Catalyst 6500 Series Ethernet modules:
WS-X6704-10GE
WS-X6908-10G-2T and WS-X6908-10G-2TXL
WS-X6748-GE-TX
WS-X6848-TX-2T and WS-X6848-TX-2TXL
WS-X6748-SFP
Cisco Catalyst 6807-XL Switch Hardware Installation Guide
OL-30656-01 3
Product Overview
Supervisor Engine
