Power Cord Part Number and Reference
Illustration
Cordset
Rating
AC Source Plug
Type
Locale
Figure 28: CAB-AC-2500W-US1= (Japan, North
America [Nonlocking Plug] 200 to 240 VAC
operation), on page 71
16 A, 250
VAC
NEMA 6-20Japan, North America
(Nonlocking Plug) 200
to 240 VAC Operation
Figure 29: CAB-AC-C6K-TWLK= (Japan,
North America [Locking Plug] 200 to 240 VAC
operation), on page 72
16 A, 250
VAC
NEMA L6-20Japan, North America
(Locking Plug)200 to
240 VAC Operation
Figure 30: CAB-7513AC= (Japan, North
America100 to120 VAC operation), on page
73
20 A, 125
VAC
NEMA 5-20Japan, North America
100 to 120 VAC
operation
9
Figure 31: CAB- L520P - C19 -US= (North
America), on page 73
20 A, 125
VAC
NEMA L5 -20North America
Figure 32: CAB-C19-CBN= (PDU), on page
73
16 A, 250
VAC
IEC 60320 C19
IEC 60320 C20
Power Distribution Unit
(PDU)
10
Figure 33: CAB-7513ACSA (South Africa), on
page 73
16 A, 250
VAC
IEC 884-1South Africa
Figure 34: CAB-ACS-16= (Switzerland), on
page 74
16 A, 250
VAC
SEV 5934-2
Type 23
Switzerland
9
The 3000 W power supply operating on 110 VAC delivers 1400 W.
10
The PDU power cable is designed for users who power their switch from a PDU. The end of the cable that plugs into the chassis power supply has a C19
connector; the other end of the cable that connects to the PDU has a C20 connector .
Cisco Catalyst 6807-XL Switch Hardware Installation Guide
68 OL-30656-01
Power Supply Specifications
3000 W Power Supply AC Power Cords
