Figure 15: Locations of Screw Holes and Pressure Vent at the Back of the Antenna
The mounting hole location on the articulating mount flange.
VESA 75 mount pattern3Pressure Vent1
Tether anchor4Grounding Point2
View the assembly of the Cisco C-ANT9104 antenna with the Cisco Catalyst 9130AX AP.
Removing back plate will void product warranty.
Note
Introduction to Cisco Catalyst 9130 Access Point with 9104 Stadium Antenna
10
Introduction to Cisco Catalyst 9130 Access Point with 9104 Stadium Antenna
Dimensions of the Antenna and Brackets
