Figure 16: Assembly view of C-ANT9104 Antenna
Back plate4Cisco C-ANT9104 Antenna1
Ethernet and Console jumper cables5DART cable connecting the C9130AX
AP with the C-ANT9104 Antenna
2
Cisco Catalyst 9130AX AP3
Figure 17: Locations of the Screw Holes on the Articulating Mount Flange
Pole / Mast mounting set screw holes1
Introduction to Cisco Catalyst 9130 Access Point with 9104 Stadium Antenna
11
Introduction to Cisco Catalyst 9130 Access Point with 9104 Stadium Antenna
Dimensions of the Antenna and Brackets
