Tightening ValuesQuantityPartItem #
3.0 to 3.5 Nm2Set screws (mast/pole mount only)6
Dimensions of the Antenna and Brackets
The dimensions noted in the following illustrations are all in millimeters, unless noted otherwise.
Figure 14: Dimensions of the Antenna with Brackets and Cables
The pressure vent and mounitng screw hole locations at the back of the antenna.
