Figure 36: Inserting the StackWise-320 Adapter

StackWise port2StackWise-320 adapter1

Step 4 Align and insert the StackWise cable connector into the StackWise adapter in the StackWise port. Push inwards

until the spring latch locks into the slot.

Figure 37: Installing the StackWise-320 Cable in a StackWise Port

Stacking cable2StackWise-320 adapter1

Cisco Catalyst 9300 Series Switches Hardware Installation Guide

Installing a Switch

Connecting a StackWise-320 Cable
