DescriptionItem
Pluggable Interface Module 0/5/0 (PIM)3
Pluggable Interface Module (PIM)
The PIM is a pluggable unit used to connect to a Wireless (LTE) interface. Details on the PIM are found in
Pluggable Interface Modules, page -29 .
SSD Module
The IR1800 will support one Solid State Drive (SSD) Module. Details on the module are found
GNSS Module
The IR1800 will support one GNSS module. The GNSS module will be used in addition to the ones integrated
in the pluggable LTE module for more accurate Dead Reckoning (DR) performance.
Details on the GNSS model are found in GNSS Pluggable Module, page -37 .
Wi-Fi Module
The Wi-Fi module will be supported in a future software release.
Gigabit Ethernet Combo Port
The IR1800 supports a single combo Fiber/Copper port (SFP/RJ45). The SFP supports standard 1000Base-X
or 100Base-FX Ethernet over single-mode or multi-mode optics. Industrial SFPs must be used for the system
to meet the operating temperature from -40C to +60C. If commercial or extended temperature Grade of SFP
is used, the system operating temperature must be de-rated.
SFP Modules
Class 1 laser product. Statement 1008
Danger
The IR1800 Ethernet SFP module provides connections to other devices. These field-replaceable transceiver
modules provide the uplink interfaces. Local connectors (LCs) provide the fiber-optic connection. RJ-45
connectors allow copper connections. You can use any combination of the supported SFP modules listed in
the table that follows.
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
17
Product Overview
Pluggable Interface Module (PIM)
