Cisco Catalyst IR1800 Rugged Series - Reset Button; Supported Cisco Antennas and Antenna Accessories

LED StatusDescriptionLED
Number
Steady Green - Port is up with link
Flashing Green - Link with activity
Off - Port is off/down
4 GE LAN ports labeled 1/0, 1/1, 1/2, 1/3
See the IR1800 Software
Configuration Guide for IOS-XE
Naming conventions.
Note
7
Steady Green - POE/POE+ power supplied on one LAN Port
Off - No POE/POE+ power on any LAN port
PoE Power Status8
Steady Green - Port is up with link
Flashing Green - Link with activity
Off - No link or port is off
RJ45 Gigabit Ethernet WAN
Either the SFP or the RJ45 LED
will be on depending on what type
of interface is used on the combo
port.
Note
9
Steady Green - Port is up with link
Flashing Green - Link with activity
Off - No link or port is off
SFP Gigabit Ethernet WAN
Either the SFP or the RJ45 LED
will be on depending on what type
of interface is used on the combo
port.
Note
10
Reset Button
The Reset button resets the router configuration to the default configuration set by the factory. To restore the
router configuration to the default configuration set by the factory, use a standard size #1 paper clip with wire
gauge 0.033 inch or smaller and simultaneously press the reset button while applying power to the router.
The reset button will not cause a reset while the device is running.
Supported Cisco Antennas and Antenna Accessories
The IR1800 must have a Pluggable Module with antenna ports installed in order to connect antennas. The
base unit does not have any wireless capabilities on its own.
The Antenna Selection and Installation, page -23 chapter lists the supported Antennas and Accessories for
the Cisco IR1800 with a wireless Pluggable Module. For detailed information about Cisco Antennas for the
Industrial Routers, please refer to the following guide:
Cisco Industrial Routers and Industrial Wireless Access Points Antenna Guide:
http://www.cisco.com/c/en/us/td/docs/routers/connectedgrid/antennas/installing-combined/industrial-routers-and-industrial-wireless-antenna-guide.html
