Cisco Catalyst IW9165D User Manual

Antenna NameConnectorAntenna Gain (dBi)PID
Cisco 5 GHz 15 dBi Dual-Port
Polarization Diverse Directional
Panel Antenna
N female
(x2)
1515—IW-ANT-PNL-515-N=
2.4/5 GHz Tri-Band Omnidirectional
Dipole Antenna, Vertically Polarized,
Self-Identifying
N male774IW-ANT-OMV-2567-N=
2.4/5 GHz Tri-Band Omnidirectional
Dipole Antenna, Horizontally
Polarized, Self-Identifying
N male774IW-ANT-OMH-2567-N=
Cisco Aironet Dual-Band
Omnidirectional Dipole Antenna
(White)
N male7—4AIR-ANT2547V-N=
Cisco Aironet Dual-Band
Omnidirectional Dipole Antenna
(Gray)
N male7—4AIR-ANT2547VG-N=
Cisco Aironet Dual-Band
Omnidirectional Dipole Antenna
(Gray), Self-Identifying
N male7—4AIR-ANT2547VG-NS=
Cisco Aironet Dual-Band
Omnidirectional Dipole Antenna
(Gray)
N male8—6AIR-ANT2568VG-N=
Cisco Aironet Dual-Band
Omnidirectional Dipole Antenna
(Gray), Self-Identifying
N male8—6AIR-ANT2568VG-NS=
Cisco Aironet 5 GHz 8 dBi
Omnidirectional Dipole Antenna
N male87—AIR-ANT5180V-N=
Cisco Aironet 5 GHz 13 dBi
Dual-Port Dual-Polarized Directional
Panel Antenna
N male (x2)13——AIR-ANT5114P2M-N=
For installation instructions and detailed information on any of these antennas, refer to the antenna data sheet
on Cisco.com, or see the antenna guides at:
• Cisco Industrial Routers and Industrial Wireless Access Points Antenna Guide
• http://www.cisco.com/c/en/us/support/wireless/aironet-antennas-accessories/
products-installation-guides-list.html
Follow all safety precautions when installing the antennas. For information on safety, see Safety Precautions
when Installing Antennas, on page 41.
