Grommet4RJ-45 cable1
Ferrule5Gasket2
Clamp nut6PG13 body3
Step 2 Plug the RJ-45 cable into the RJ-45 connector in the chassis.
Step 3 Thread the PG13 body (with gasket) into the chassis.
Step 4 Insert the grommet into the ferrule, and press it into the PG13 body.
Step 5 Tighten the clamp nut onto the PG13 body until the grommet compresses onto the RJ-45 cable.
Cisco Catalyst IW9165D Heavy Duty Access Point Hardware Installation Guide
33
Installation Overview
Connecting to the RJ-45 Port Using Cable Gland
