Connecting to the Home Network
The following diagrams illustrate examples of the connections you can use to
connect your set-top to your in-home network. Contact your service provider for the
recommended connection method for your home.
Note: The in-home coaxial and phoneline wiring networks use HomePNA
™
3.1
technology
NETWORK USB
TO WALL
(VIDEO IN)
TO TV
(VIDEO OUT)
POWER
TO WALL
(VIDEO IN)
TO TV
(VIDEO OUT)
POWER
T13211
Coaxial
In-Home
Coaxial
Network
Wall
Twisted Pair
OR
In-Home
Twisted Pair
Network
Wall
Adapter
CAT-5
OR
In-Home
CAT-5
Network
Wall
