Cisco CIS430 - Connecting to an SDTV with an RCA-Type Connector

20
Connecting to an SDTV with an RCA-Type Connector
Cables Used in this Confi guration
• 1 RCA-type Video Cable
• 1 Set Audio Left/Right Cables
CIS430 DVR
T13228
VIDEO
OUT
AUDIO
OUT
TO WALL
(VIDEO IN)
NETWORK USB
OPTICAL
TO TV
(VIDEO OUT)
POWER
LR
Pr
Pb Y
S-VIDEO
Back of
SDTV
RIGHT
INOUT
LEFT
AUDIO
INOUT
CABLE/
ANTENNA
VIDEO
INOUT
Note: Image may vary from actual product.
WARNING:
Electric shock hazard! Unplug all electronic devices before connecting or
disconnecting any device cables to the set-top.
