Cisco CIS430 User Manual

19
Note: Image may vary from actual product.
WARNING:
Electric shock hazard! Unplug all electronic devices before connecting or
disconnecting any device cables to the set-top.
Connecting to an SDTV with Component (YPbPr)
Connectors
Cables Used in this Confi guration
• 1 Component Video Cable (YPbPr)
• 1 Set Audio Left/Right Cables
Note: The set-top must be set to the proper output mode, typically 480i or 480p.
CIS430 DVR
T13227
VIDEO
OUT
AUDIO
OUT
TO WALL
(VIDEO IN)
NETWORK USB
OPTICAL
TO TV
(VIDEO OUT)
POWER
LR
Pr
Pb Y
S-VIDEO
Back of SDTV
RF OUT
RF IN
RL
AUDIO
IN
VIDEO
IN
RL
AUDIO
OUT
VIDEO
OUT
Y
PB
PR
