8
Cisco ENCS 5400-W Series Quick Start Guide
Unpacking and Installing the ENCS 5400-W Device
Step 3 To wall-mount the device:
a. As shown in Figure 5, attach the brackets to the device using the screws and plastic spacers provided
with the mounting kit. Use two screws and two plastic spaces should be used to attach each bracket
to the chassis.
b. Fix the router to the wall using the brackets that you attached to the device. The screws for attaching
the device to the wall are not provided with the kit. Depending on the type of wall (wood, brick,
stone etc), use appropriate screws to fix the device to the wall.
Note Route the cables so that they do not put a strain on the connectors or mounting hardware.
Figure 5 Bracket Installation for Wall Mounting the Cisco ENCS 5400-W
