Cisco Expressway CE1200 Installation Guide

Hardware Components
The CE1200 is based on a UCS C220 M5L server, with the following components:
Item Part Quantity
Chassis UCS-C220-M5L 1
Processor UCS-CPU-6134 (3.2 GHz 6134/130W 8C/24.75MB Cache/DDR4
2666MHz)
1
RAM EXP-MR-X16G1RS-H (16GB) DDR4-2666-MHz RDIMM/PC4-
21300/single rank/x4/1.2v
2
Hard Disk
UCS-HD2T7KL12N 2 TB 12G SAS 7.2K RPM LFF HDD 2
RAID Controller UCSC-MRAID1GB-KIT SAS RAID KIT for C220M5l 1
NIC UCSC-PCIE-ID10GF Intel X710-DA2 dual-port 10G SFP+ NIC 1
EXP-10GSFP-SR-MP (10Gb SR Fiber SFP) 2
EXP-1GSFP-T (1Gb Copper SFP) 2
PSU UCSC-PSU1-770W & power cable 2
TPM UCSX-TPM2-002 (Trusted Platform Module 2.0) 1
SDCard UCS-SD-32G-S (32GB SD Card for UCS servers) 1
Miscellaneous UCSC-RAILF-M4 (Rail kit) 1
UCSC-HS-C220M5 (Heat sink) 1
UCSC-PSU-BLKP1U (blanking panel) 1
UCS-MSTOR-SD (Mini Storage Carrier for SD) 1
Accessory Kit 1
Bezel 1
Table 2 Components and part numbers for the CE1200 Appliance
Field-Replaceable Components
These components are field replaceable:
■ Hard disks
■ Power supply units (PSUs)
■ Fan module
■ SFP network connection modules (1 Gb and 10 Gb)
CAUTION: To avoid compatibility issues use only the supplied SFPs, and follow the other requirements for
SFPs in Task 2: Insert the SFP Network Connection Modules, page 11
Returns or Replacements
If you need to begin a Return MaterialAuthorization (RMA) for any reason, go to
http://www.cisco.com/web/ordering/cs_info/or3/o32/Return_a_Product/WebReturns/product_Online_web_
returns.html.
7
Cisco Expressway CE1200 Appliance Installation Guide
Hardware Components

Cisco Expressway CE1200 Specifications

General

Brand	Cisco
Model	Expressway CE1200
Category	Server
Language	English
