• See Remove and Replace the Fan Tray, on page 78 for the procedure for removing and replacing the
fan tray in the Firepower 2130 and 2140.
• See Ground the Chassis, on page 54 for the procedure for using the grounding lug to ground the chassis.
• See Power Supply Modules, on page 23 for a description of the power supply module LEDs.
• See Front Panel LEDs, on page 10 for a description of the fan LEDs.
Network Modules
The Firepower 2130 and 2140 contain one network module slot that provides optical or electrical network
interfaces. Network modules are optional, removable I/O modules that provide either additional ports or
different interface types. The Firepower network module plugs into the chassis on the front panel.
For More Information
• See 10-G Network Module , on page 17 for a description of the 10-G network module.
• See Supported SFP/SFP+ Transceivers, on page 26 for a list of supported SFPS.
• See Remove and Replace the Network Module, on page 67 for the procedure for removing and replacing
network modules.
10-G Network Module
The following figure shows the front panel of the 10-G network module (FPR2K-NM-8X10G). The
FPR2K-NM-8X10G is a single-wide module that supports hot swapping. The eight ports are numbered from
top to bottom, left to right.
The FPR2K-NM-8X10G is NEBS-compliant.
Note
You can fit four copper SFPs in either the top row of ports or the bottom row of ports. Both rows cannot be
populated at the same time, because of the port row spacing.
Note
Cisco Firepower 2100 Series Hardware Installation Guide
17
Overview
Network Modules
