DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure
Example:
RP/0/RP0/CPU0:router# configure
Step 1
Configures the instance named cgn1 for the CGN application and enters
CGN configuration mode.
service cgn instance-name
Example:
RP/0/RP0/CPU0:router(config)# service
cgn cgn1
RP/0/RP0/CPU0:router(config-cgn)#
Step 2
Configures the service type keyword definition for CGN NAT44
application.
service-type nat44 nat1
Example:
RP/0/RP0/CPU0:router(config-cgn)#
service-type nat44 nat1
Step 3
Saves configuration changes.end or commit
Example:
RP/0/RP0/CPU0:router(config-cgn)# end
or
Step 4
•
When you issue the end command, the system prompts you to commit
changes:
Uncommitted changes found, commit them before exiting
(yes/no/cancel)?
RP/0/RP0/CPU0:router(config-cgn)#
commit
[cancel]:
◦
Entering yes saves configuration changes to the running
configuration file, exits the configuration session, and returns
the router to EXEC mode.
◦
Entering no exits the configuration session and returns the
router to EXEC mode without committing the configuration
changes.
◦
Entering cancel leaves the router in the current configuration
session without exiting or committing the configuration changes.
•
Use the commit command to save the configuration changes to the
running configuration file and remain within the configuration session.
Configuring an Inside and Outside Address Pool Map
Perform this task to configure an inside and outside address pool map with the following scenarios:
•
The designated address pool is used for CNAT.
•
One inside VRF is mapped to only one outside VRF.
Cisco IOS XR Carrier Grade NAT Configuration Guide for the Cisco CRS Router, Release 5.2.x
28 OL-32659-01
Implementing Carrier Grade NAT on Cisco IOS XR Software
Configuring an Inside and Outside Address Pool Map
