If one or more FPD needs an upgrade, then this can be accomplished using the following
steps. Make sure that the fpd pie is loaded and activated. If found different, follow the
upgrade procedure in Line Card Upgrade.
Note
•
After insertion, the card remains in "IOS XR RUN" state until you install the appropriate cgn service
pie.
•
After installing the cgn service pie, the card goes to "FAILED" state until you complete the configuration
mentioned in next step. These log messages appear on the console.
LC/0/3/CPU0:Sep 28 23:36:36.815 : plim_services[241]: plim_services_init[2063] Uknown
role Retrying.., Role = -7205769247857836031
LC/0/3/CPU0:Sep 28 23:37:59.341 : plim_services[241]: service_download_thread[3873]
App img download max-retries exhausted, 'plim_services' detected the 'warning' condition
'Operation not okay'
LC/0/3/CPU0:Sep 28 23:37:59.342 : plim_services[241]: plim_services_tile_failed[752]
TILE0 failed
RP/0/RP1/CPU0:Sep 28 23:38:18.494 : invmgr[240]: %PLATFORM-INV-6-NODE_STATE_CHANGE :
Node: 0/3/0, state: FAILED
•
After Successful Boot Up:
RP/0/RP0/CPU0:router#show platform
Sun Dec 20 07:15:38.893 UTC
Node Type PLIM State Config State
-----------------------------------------------------------------------------
0/0/CPU0 MSC Services Plim IOS XR RUN PWR,NSHUT,MON
0/0/0 MSC(SPA) CGSE-TILE OK PWR,NSHUT,MON
0/1/CPU0 MSC Jacket Card IOS XR RUN PWR,NSHUT,MON
0/1/0 MSC(SPA) 8X1GE OK PWR,NSHUT,MON
•
Control connection to CGSE, One ServiceInfra Interface per CGSE & IPv4 address of local significance.
Minimum of two valid IPv4 unicast addresses are required for each ServiceInfra SVI. The Serviceinfra
interface removal/modification needs CGSE LC reload.
outer(config)
interface ServiceInfra1
ipv4 address 3.1.1.2 255.255.255.252
service-location 0/0/CPU0
logging events link-status
commit
router(config)
hw-module service cgn location 0/0/CPU0
commit
This configuration has to be replicated for Standby CGSE Card. The serviceinfra IP has
to be different.
Note
•
Specify the service role(cgn) for the given CGSE location
You need to reload the card. It takes about 15minutes.
router#
hw-module location 0/0/CPU0 reload
WARNING: This will take the requested node out of service.
Do you wish to continue?[confirm(y/n)] y
Cisco IOS XR Carrier Grade NAT Configuration Guide for the Cisco CRS Router, Release 5.2.x
68 OL-32659-01
Implementing Carrier Grade NAT on Cisco IOS XR Software
Configuring the Carrier Grade Service Engine
