Figure 2: Cisco IR809 Front Panel
Grounding Point8S0 RS232 DCE/RS485 Combo Port1
Mini type-B USB console/debug port9S1 RS232 DTE only2
SYS LED10GE0 (10/100/1000)3
Alarm LED11GE1 (10/100/1000)4
WAN/WWAN LEDs12USB 2.0 (Type-A Host Port)5
SIM Card LEDs13RESET Button6
DC Power/Alarm Connector7
LEDs are viewable from the top and from the front of the IR809.
Note
The following figure shows the back panel details of the Cisco IR809.
Product Overview
3
Product Overview
General Description
