Cisco IW3702 User Manual

Indoor Cisco Aironet Dual-Band Omnidirectional Antenna Directly and Cable Connected to Access Point
Table 9: Indoor Dual-Band Omnidirectional Antenna Directly and Cable Connected to Access Point
DescriptionItem
4 x indoor Cisco Aironet dual-band AIR-ANT2547V-N or
AIR-ANT2547VG-N omnidirectional antennas connected to
the IW3702-2E-UXK9 or IW3702-2E-x-K9 model:
•
2 x antennas directly mounted on top panel side.
•
2 x antennas connected via cables on the bottom side.
Antenna Arrangement
IW3702-2E-UXK9 or IW3702-2E-x-K9Access Point
You need:
•
2 x N(f) to N(f) RF adapters. Cisco PID
AIR-ACC370-NF-NF.
•
2 x DC pass, N(m)-N(f) lightning arrestors. Cisco PID
CGR-LA-NM-NF.
Installed on the router ports with cables.
Lightning arrestors must be appropriately grounded
to infrastructure system ground designed to conduct
lightning currents to Earth ground.
Note
Adapter and/or Lightning Arrestor
For indoor cable routing, the deployment must balance the
requirements of Fire Code, Electrical Code, and any other
applicable regulations, versus RF cable type, cost, RF cable
length, and RF cable insertion loss.
Indoor Cable
Select from:
• 2 x N(m)-R/A to N(m)-STR, LMR-400-DB , 5’ RF cable,
Cisco PID: CAB-L400-5-N-N
• 2x N(m)-STR to N(m)-STR, LMR-400-DB , 5’ RF cable,
Cisco PID: CAB-L400-5-N-NS
• 2x N(m)-R/A to N(m)-STR, LMR-400-DB , 10’ RF cable,
Cisco PID: AIR-CAB010LL-N
• 2 x N(m)-R/A to N(m)-STR, LMR-400-DB, 20’ RF cable,
Cisco PID: CAB-L400-20-N-N
• 2 x N(m)-R/A to N(m)-STR, LMR-600-DB, 30’ RF cable,
Cisco PID: CAB-L600-30-N-N
• 2 x N(m)-STR to N(m)-STR, LMR-400-DB, 25’ RF cable
with petrochemical and oils resistance, Cisco PID
AIR-CAB025HZ-N
Outdoor Cable
31

Cisco IW3702 Specifications

General

Model	IW3702
Category	Wireless Access Point
Wireless Standards	802.11a/b/g/n/ac
Frequency Bands	2.4 GHz and 5 GHz
Ingress Protection	IP67
Ethernet Ports	2 x 10/100/1000BASE-T
Power Source	PoE (802.3af)
Humidity	5% to 95% (non-condensing)
Security	802.1X
Mounting	Pole, wall
