Cisco IW3702 User Manual

DescriptionItem
Select from:
•
White model, Cisco PID AIR-ANT2547V-N
•
Grey Model, Cisco PID AIR-ANT2547VG-N
4 x Cisco Aironet dual-band omnidirectional antennas are
required. The antenna specifications are:
•
2400-2484MHz, 5150-5875MHz, dual-band, WiFi,
operating frequency range
•
4 dBi (2.4 GHz), 7 dBi (5 GHz) gain
•
11 in. (27.94 cm) stick antennas for indoor or outdoor
use with a type N(m) connector
•
IP67 rated, -40 to 185°F (-40°C to 85°C) operating
temperature range
Antenna
Indoor Only Dual-Band Omnidirectional Articulating Joint Antenna and Access Point
Table 10: Indoor only Dual-Band Omnidirectional Articulating Joint Antenna and Access Point
DescriptionItem
4 x Cisco Aironet dual-band AIR-ANT2524DW-R
omnidirectional articulating joint indoor antennas connected
to access point with adapters in between. This configuration
is for indoor applications where swivel mount is desirable to
control dipole antenna tilt/polarization.
Antenna Arrangement
IW3702-2E-UXK9 or IW3702-2E-x-K9
Do not use this configuration with the
IW3702-4E-UXK9 or IW3702-4E-x-K9 model. For
the -4E models, all four antenna ports are on one side,
and would be too close to each other for optimal
MIMO IEEE 802.11ac operation with all antennas
directly connected.
Note
Access Point
N/AIndoor Cable
You need:
•
4 x N(m) to RP-TNC (jack), RF coax adapters. Cisco
PID AIR-ACC370-NM-RF.
No lightning arrestors are
required.
Note
Adapter and/or Lightning Arrestor
32

Cisco IW3702 Specifications

General

Model	IW3702
Category	Wireless Access Point
Wireless Standards	802.11a/b/g/n/ac
Frequency Bands	2.4 GHz and 5 GHz
Ingress Protection	IP67
Ethernet Ports	2 x 10/100/1000BASE-T
Power Source	PoE (802.3af)
Humidity	5% to 95% (non-condensing)
Security	802.1X
Mounting	Pole, wall
