Cisco IW3702 User Manual

DescriptionItem
N/AOutdoor Cable
4 x Cisco Aironet dual-band AIR-ANT2524DW-R indoor
articulating joint omnidirectional antennas are required. The
antenna specifications are:
• 2400–2500MHz, 5150–5850MHz, dual-band, WiFi,
operating frequency range
•
2 dBi (2.4 GHz), 4 dBi (5 GHz) gain
•
Articulating joint.
•
6.63 in. (16.95 cm) dipole antennas for indoor only use.
•
RP-TNC (plug) connector.
•
-4 to 140°F (-20°C to 60°C) operating temperature range.
•
White color model, Cisco PID AIR-ANT2524DW-R.
Antenna
Outdoor Cisco Aironet Four-Port Dual-Band Polarization-Diverse Array Antenna and Access Point
Table 11: Outdoor Four-Port Dual-Band Polarization-Diverse Array Antenna and Access Point
DescriptionItem
1 x Cisco Aironet AIR-ANT2513P4M-N four-port dual-band
polarization-diverse array antenna located outdoors, connected
by external cable to the access point antenna connector.
Antenna Arrangement
IW3702-2E-x-K9, IW3702-4E-x-K9, IW3702-2E-UXK9, or
IW3702-4E-UXK9
Access Point
4 x DC pass, N(m)-N(f) lightning arrestors. Cisco PID
CGR-LA-NM-NF.
Lightning arrestors must be appropriately grounded
to infrastructure system ground designed to conduct
lightning currents to Earth ground.
Note
Adapter and/or Lightning Arrestor
N/AIndoor Cable
33

Cisco IW3702 Specifications

General

Model	IW3702
Category	Wireless Access Point
Wireless Standards	802.11a/b/g/n/ac
Frequency Bands	2.4 GHz and 5 GHz
Ingress Protection	IP67
Ethernet Ports	2 x 10/100/1000BASE-T
Power Source	PoE (802.3af)
Humidity	5% to 95% (non-condensing)
Security	802.1X
Mounting	Pole, wall
