2-10
Cisco ME 3400E Ethernet Access Switch Hardware Installation Guide
OL-16447-01
Chapter 2 Switch Installation
Installing the Switch
Attaching Brackets for 23-Inch Racks
Figure 2-6 shows how to attach brackets for the 23-inch racks on all switches except the
Cisco ME 3400EG-2CS-A.
Figure 2-6 Attaching Brackets for 23-Inch Racks
1 Phillips flat-head screws 3 Rear-mounting position
2 Front-mounting position 4 Mid-mounting position
