A-4
Cisco ME 3800X and ME 3600X Switch Hardware Installation Guide
OL-22168-01
Appendix A Technical Specifications
Environmental and Technical Specifications for the Switch
Note If you install one AC and one DC power supply module in a switch, the power specifications are similar
to two installed DC power supply modules.
Table A-4 Technical Specifications—ME-3600X-24TS-M
Physical Dimensions
Weight 14.15 lb (6.42 kg) (no FRU installed)
Dimensions (H x W x D) 1.72 x 17.50 x 20.39 in. (4.37 x 44.45 x 51.79 cm)
AC Power Requirements
Input voltage 100 to 240 VAC ± 10% (autoranging), 50 to 60 Hz.
Power consumption with 1 AC power
supply module and 1 fan module
installed
Total: 656 BTUs per hour (maximum).
Maximum: 192 W (worst-case SFPs, SFP+ LRM, 100% traffic).
Typical: 150 W (12 SFPs with 1000Base-SX, 2 SFP+ with SR, 100% traffic).
Minimum: 117 W (no cables or SFP modules installed).
Power rating: 120 V (0.214 KVA), 230 V (0.209 KVA).
Power consumption with 2 AC power
supply modules installed
Total: 677 BTUs per hour (maximum).
Maximum: 198 W (worst-case SFPs, SFP+ LRM, 100% traffic).
Typical: 158 W (12 SFPs with 1000BASE-SX, 2 SFP+ with SR, 100% traffic).
Minimum: 126 W (no cables or SFP modules installed).
Power rating: 120 V (0.220 KVA), 230 V (0.215 KVA).
DC Power Requirements
Input voltage 18 to 32 VDC and 36 to 72 VDC.
Power consumption with 1 DC power
supply module and 1 fan module
installed
Total: 711 BTUs per hour (maximum).
Maximum: 208 W (18 VDC input, worst-case SFPs, SFP+ LRM, 100% traffic).
Typical: 151 W (48 VDC, 12 SFPs with 1000BASE-SX, 2 SFP+ with SR, 100%
traffic).
Minimum: 117 W (48 VDC, no cables or SFP modules installed).
Power consumption with 2 DC power
supply modules installed
Total: 697 BTUs per hour (maximum).
Maximum: 204 W, 18 VDC input (maximum fan speed, all ports linked).
Typical: 157 W (48 VDC, SFP modules installed, 12 ports linked).
Minimum: 124 W (48 VDC, no SFP modules installed).
