Appendix B Connector and Cable Specifications
Cables and Adapters
Cables and Adapters
• SFP and SFP+ Module Cabling, page B-5
• Cable Pinouts, page B-7
• Console Port Adapter Pinouts, page B-8
SFP and SFP+ Module Cabling
Each port must match the wave-length specifications on the other end of the cable, and for reliable
communications, the cable must not exceed the required cable length. Copper 1000BASE-T SFP
transceivers use standard four twisted-pair, Category 5 (or greater) cable at lengths up to 328 feet (100
meters).
Table B-2 Fiber-Optic SFP Module Port Cabling Specifications
SFP Module
Wavelength
(nanometers) Fiber Type
Core
Size/Cladding
Size (micron)
Modal
Bandwidth
(MHz/km)
1
Cable Distance
100BASE-BX
(GLC-FE-100BX-D
GLC-FE-100BX-U)
1310 TX
1550 RX
SMF G.652
2
— 32,810 feet (10 km)
100BASE-EX 1310 SMF G.652
2
— 131,240 ft (40 km)
100BASE-FX
(GLC-GE-100FX)
1310 MMF 50/125
62.5/125
500
500
6,562 feet (2 km)
6,562 feet (2 km)
100BASE-FX
(GLC-FE-100FX)
1310 MMF 50/125
62.5/125
500
500
6,562 feet (2 km)
6,562 feet (2 km)
100BASE-LX
(100BASE-LX10)
1310 SMF G.652
2
— 32,810 feet (10 km)
100BASE-ZX 1550 SMF G.652 — 262,480 ft (80 km)
1000BASE-BX10-D
(GLC-BX-D)
1490 TX
1310 RX
SMF G.652
2
— 32,810 feet (10 km)
1000BASE-BX10-U
(GLC-BX-U)
1310 TX
1490 RX
SMF G.652
2
— 32,810 feet (10 km)
1000BASE-SX
(GLC-SX-MM)
850 MMF 62.5/125
62.5/125
50/125
50/125
160
200
400
500
722 feet (220 m)
902 feet (275 m)
1640 feet (500 m)
1804 feet (550 m)
1000BASE-LX/LH
(GLC-LH-SM)
1310 MMF
3
SMF
62.5/125
50/125
50/125
G.652
2
500
400
500
—
1804 feet (550 m)
1804 feet (550 m)
1804 feet (550 m)
32,810 feet (10 km)
1000BASE-ZX
(GLC-ZX-SM
1550 SMF G.652
2
— 43.4 to 62 miles
(70 to 100 km)
4
CWDM 1470, 1490, 1510, 1530,
1550, 1570, 1590, 1610
SMF G.652
2
— 62 miles (100 km)
