External Antenna Ports
The MR46E has 6 external antenna ports
Ethernet Ports
The MR46E features a Gigabit Ethernet RJ45 port that accepts 802.3at power (labeled “Eth0, PoE”). This port should be
used for uplink to your WAN connection.
The port labeled “PoE” accepts 802.3at power and should be used as the primary uplink to your LAN/WAN.
Power Source Options
The MR46E access point can be powered using either the Meraki AC Adapter, PoE Injector (both sold separately), or a
third-party PoE switch.
4
