Cisco N9K-C93180YC-FX3 User Manual

CONTENTS
Overview 1
CHAPTER 1
Overview 1
Preparing the Site 7
CHAPTER 2
Temperature Requirements 7
Humidity Requirements 7
Altitude Requirements 7
Dust and Particulate Requirements 8
Minimizing Electromagnetic and Radio Frequency Interference 8
Shock and Vibration Requirements 9
Grounding Requirements 9
Planning for Power Requirements 9
Airflow Requirements 10
Rack and Cabinet Requirements 11
Clearance Requirements 11
Installing the Switch Chassis 13
CHAPTER 3
Safety 13
Installation Options with Rack-Mount Kits 16
Airflow Considerations 17
Installation Guidelines 17
Unpacking and Inspecting the Switch 18
Installing the Switch Using the NXK-ACC-KIT-1RU Rack-Mount Kit 18
Installing the Switch Using the N3K-C3064-ACC-KIT Rack-Mount Kit 22
Installing the Airflow Sleeve (N9K-AIRFLOW-SLV) 26
Grounding the Chassis 28
Cisco Nexus 93180YC-FX3 ACI-Mode Switch Hardware Installation Guide
iii

Cisco N9K-C93180YC-FX3 Specifications

General

Product Model	N9K-C93180YC-FX3
Manufacturer	Cisco
Category	Switch
Form Factor	1 RU
Jumbo Frame Support	Yes
Jumbo Frame Size	9216 bytes
VLAN IDs	4096
Operating System	Cisco NX-OS
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-40 to 158°F (-40 to 70°C)
Ports	48 x 25-Gbps SFP28, 6 x 100-Gbps QSFP28
Latency	Sub-microsecond
Power Supply	Redundant
AC Power Input	100 to 240 VAC
Humidity	5 to 95% (noncondensing)
Dimensions	1.72 x 17.3 x 22.5 inches
