Figure 42: NCS-57B1-6D24-SYS and NCS-57B1-5DSE-SYS Ground Lug

Figure 43: NCS-57C3-MOD Ground Lug

Pan-head screws2Grounding lug1

Hardware Installation Guide for Cisco NCS 5700 Series Fixed-Port Routers

Install the Chassis

Ground the Chassis
