Cisco Nexus 9300-FX

Supported Transmission
Speeds
Maximum Number of
Uplink Connections
Spine Switch or Modular Line Card
1, 10, 40 or 100 Gigabits
40 or 100 Gigabits
1 or 10 Gigabits
48 QSFP28 fixed ports
16 QSFP28 fixed ports
2 SFP+ fixed ports
Cisco Nexus 9364C switch
1, 10, 25, 40, 50, or 100
Gigabits
32 QSFP28 fixed portsN9K-X9732C-EX line card supported by Cisco Nexus
9504, 9508 modular switches
1, 10, or 40 Gigabits36 QSFP+ fixed portsN9K-X9736PQ line card supported by Cisco Nexus
9504, 9508, and 9516 modular switches
To determine which transceivers, adapters, and cables are supported by this switch, see
http://www.cisco.com/c/en/us/support/interfaces-modules/transceiver-modules/products-device-support-tables-list.html.
To see the transceiver specifications and installation information, see
http://www.cisco.com/c/en/us/support/interfaces-modules/transceiver-modules/products-installation-guides-list.html.
Statement 1053—Class 1M Laser Radiation
Class 1M laser radiation when open. Do not view directly with optical instruments.
Warning
Statement 1055—Class I and Class 1M Laser
Class I (CDRH) and Class 1M (IEC) laser products.
Warning
Statement 1056—Unterminated Fiber Cable
Invisible laser radiation may be emitted from the end of the unterminated fiber cable or connector. Do not
view directly with optical instruments. Viewing the laser output with certain optical instruments (for example,
eye loupes, magnifiers, and microscopes) within a distance of 100 mm may pose an eye hazard.
Warning
Before you begin
• The leaf and spine switches in the fabric must be fully installed in their racks and grounded.
• If there are modular switches in the fabric, their ACI-mode line cards must already be installed. The line
cards can be of the following types:
• 36-port 40-Gigabit (N9K-X9736PQ)
• 32-port 100-Gigabit (N9K-X9732C-EX) (supported by Cisco Nexus 9504 and 9508 modular
switches)
Cisco Nexus 9348GC-FXP ACI Mode Hardware Installation Guide
30
Connecting the Switch to the ACI Fabric
Connecting Leaf Switches to Spine Switches
