Unpacking and Installing the Cisco ONS 15454 Four-Shelf and Zero-Shelf Bay Assembly
78-13271-05
Optional Kits
15454 Bay End Plate Cover Kit
The 15454 Bay End Plate Cover Kit provides a basic end plate for temporary cable protection. It contains
parts that mount flush against the rack with no major footprint change (thickness of the metal only)
against the edge of the rack to protect the cables. This plate is usually used for an aisle that is not
complete, or as an aisle guard for aisles. The end plate cover can be mounted with the 2.38-inch extender
as shown in Figure 33 or mounted directly as shown in Figure 34.
Figure 33 End plate cover assembly mounted with 2.38-inch extender
67468
End plate
Extender
