Cisco RV134W Administration Guide

VPN
Site-to-Site IPsec VPN
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 110
6
STEP 3 Click Save.
Configuring the Spoke Site
When configuring the spoke site, you will create a VPN policy for each spoke site,
for example, VPN policy Spoke1ToHub for spoke site1 and Spoke2ToHub for spoke
site2. To configure the spoke site enter the following information:
STEP 1 On the Advanced VPN Setup page, in the VPN Policy Table, click Add Row.
To configure the VPN settings for each spoke site, configure the following features:
Remote Endpoint Select IP Address from the drop-down list and
enter the IP address.
Redundant Enable Leave unchecked.
NetBIOS Leave unchecked.
Local Traffic Section >
Local IP
Select Subnet from the drop-down list.
IP Address Enter the local LAN subnet, for example,
192.168.1.0 and 192.168.74.0 for HubToSpoke1 or
192.168.1.0 and 192.168.75.0 for HubToSpoke2.
Subnet Netmask Enter 255.255.255.0, then click Add to enter the
address in the IP/Subnet List.
Remote Traffic Section
>Remote IP
Select Subnet from the drop-down list.
IP Address Enter remote LAN subnet, for example
192.168.75.0 for HubToSpoke1 or 192.168.74.0
for HubToSpoke2.
Subnet Netmask Enter 255.255.255.0, then click Add to enter the
address in the IP/Subnet List.
Add/Edit VPN Policy
Configuration > Policy
Name
Enter Spoke1ToHub or Spoke2toHub.
Policy Type Select Auto Policy from the drop-down list.
VPN Failover Leave unchecked.
