Cisco RV134W Administration Guide

Networking
Configuring LAN Settings
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 19
3
In the DSL Settings for the PTM transfer mode (RV134W), enter the following:
In the IPoE Settings section for both the ATM and PTM (RV134W) transfer modes,
enter the following information::
Virtual Circuit The Virtual Path Identifier (VPI) and
Virtual Channel Identifier (VCI) are
values used to identify your line to your
ISP’s ATM network.
SRA (Seamless Rate Adaption) Check Enable or Disable to enable or
disable the SRA, a protocol which, by
decoupling the modulation and
framing layer, can change the
transmission data rate parameters
(applied by the modulation layer).
DSL Modulation Select the DSL modulation from the
drop-down list. The default DSL
modulation is Multimode
(recommended).
Transfer Mode PTM
SRA (Seamless Rate Adaption) Check Enable or Disable to enable or
disable the SRA, a protocol which, by
decoupling the modulation and
framing layer, can change the
transmission data rate parameters
(applied by the modulation layer).
DSL Modulation Select the DSL modulation from the
drop-down list. The default DSL
modulation is Multimode
(recommended).
Auto Get IP (DHCP) Check Enable or Disable to enable or disable the Auto
get IP (DHCP) which is a method of automatically
assigning IP addresses. If disabled, manually configure
the IP address.
DNS Server Source Select Get Dynamically from ISP or Use These DNS
Servers to manually configure.

Cisco RV134W Specifications

General

Brand	Cisco
Model	RV134W
Category	Wireless Router
Language	English
