Using the Cisco SPA 500S Attendant Console
Connecting the Cisco SPA 500S Attendant Console to the IP Phone
Cisco Small Business IP Phone SPA 50X User Guide (SPCP) 59
6
STEP 7 Using an attachment arm screw, secure the attachment arm to the Cisco SPA 500S.
CAUTION Do not plug a telephone line cord into the AUX port. Use only the auxiliary cable
provided with the Cisco SPA 500S.
STEP 8
Locate the AUX IN port on the back of the Cisco SPA 500S. Connect one end of the
auxiliary cable to this port.
STEP 9 Locate the AUX port on the back of the IP phone. Connect the other end of the
auxiliary cable to this port. The Cisco SPA 500S is powered by the auxiliary cable
with the IP phone; no additional power source is required.
