Installing Your Phone
Phone Connections
Cisco Small Business IP Phone SPA 50X User Guide (SPCP) 16
2
NOTE Do not use the RJ-11 port marked “AUX.” It is reserved for connection with auxiliary
devices that are not supported with the SPCP version of the telephone firmware.
This port is not for use as a telephone line port.
CAUTION CAUTION: Do not plug a telephone line cord into the port marked “AUX.”
Phone Connections
The following photo shows where you need to connect parts of the phone.
Figure 1 Phone Connections
