Cisco TelePresence MX Series
ADMINISTRATOR GUIDE
You can control and monitor several call features using the
Call Control page.
Use + and on the volume control bar to adjust the sound
volume of your system (not the keyboard + and - keys).
Use the Mute button when you want to deactivate the
microphone for privacy reasons.
When the microphone is muted, the button is replaced by an
Unmute button. Use this button to re-activate the microphone.
First, click the Camera Control button. Then, in the window
that opens, use + and to adjust the zoom and the arrow keys
to adjust the camera’s angle.
If a camera preset is defined it is listed to the right. Apply the
preset by clicking its name.
When you load the Call Control page, the default call bit rate
and the default call protocol are shown in the Call bit rate and
Call protocol boxes, respectively. If preferred, you can select
another bit rate or another protocol from the drop down lists.
You can not change these settings during a call.
Click Show details to provide information on call rate,
encryption, as well as important video and audio parameters.
Hide details removes the information.
Call Control
Call
Call
