D14850.02 MX Series Administrator Guide (TC5.0) | 2011 NOVEMBER | © 2011 Cisco Systems, Inc. All rights reserved. www.cisco.com
23
Cisco TelePresence MX Series
ADMINISTRATOR GUIDE
Call Control

Snapshots of what the video system’s camera captures can
be obtained from the Call Control page, provided that the
feature has been enabled on the video system.
This feature might come in handy when administering the
video system from a remote location, e.g. to check the
camera view.
To use web snapshots you have to sign in with ADMIN
credentials.

NOTE: The live snapshot feature is disabled by default.
The live snapshot feature can be enabled using the Touch
controller.
 Tap More > Settings > Administrator Settings > Web
Snapshots and select .

While the Live snapshots box is checked,
a snapshot is taken approximately every
two seconds. The snapshots are displayed
in the Main source display area.


Snapshots are
displayed here.
