D14850.02 MX Series Administrator Guide (TC5.0) | 2011 NOVEMBER | © 2011 Cisco Systems, Inc. All rights reserved. www.cisco.com
52
Cisco TelePresence MX Series
ADMINISTRATOR GUIDE
Set the COM 1 serial port to be enabled/disabled.
ADMIN
<On/Off>
On: Enable the COM 1 serial port.
Off: Disable the COM 1 serial port.
SerialPort Mode: On
Specify the baud rate (data transmission rate, bits per second) for the COM 1 port on the codec.
The default value is 38400.
Connection parameters for the COM port: Data bits: 8; Parity: None; Stop bits: 1; Flow control:
None.
ADMIN
<9600/19200/38400/57600/115200>
Range: Select a baud rate from the baud rates listed (bps).
SerialPort BaudRate: 38400
Determine if login shall be required when connecting to the COM 1 port at the codec.
ADMIN
<On/Off>
On: Login is required when connecting to the codec through COM 1 port.
Off: The user can access the codec through COM 1 port without any login.
SerialPort LoginRequired: On
The SIP URI or number is used to address the system. This is the URI that is registered and used
by the SIP services to route inbound calls to the system. A Uniform Resource Identifier (URI) is a
compact string of characters used to identify or name a resource.
ADMIN
<S: 0, 255>
Format: Compact string with a maximum of 255 characters.
SIP Profile 1 URI: "sip:firstname.lastname@company.com"
When configured the incoming call will report the DisplayName instead of the SIP URI.
ADMIN
<S: 0, 255>
Format: String with a maximum of 255 characters.
SIP Profile 1 DisplayName: ""
This is the user name part of the credentials used to authenticate towards the SIP proxy.
ADMIN
<S: 0, 128>
Format: String with a maximum of 128 characters.
SIP Profile 1 Authentication 1 LoginName: ""
This is the password part of the credentials used to authenticate towards the SIP proxy.
ADMIN
<S: 0, 128>
Format: String with a maximum of 128 characters.
SIP Profile 1 Authentication 1 Password:
