Cisco TelePresence MX Series
ADMINISTRATOR GUIDE
Specify the maximum receive call rate to be used when placing or receiving calls.
ADMIN
<64..6000>
Range: Select a value between 64 and 6000 kbps.
Conference 1 MaxReceiveCallRate: 6000
Set the conference video bandwidth mode.
ADMIN
<Dynamic/Static>
Dynamic: The available transmit bandwidth for the video channels are distributed among the
currently active channels. If there is no presentation, the main video channels will use the
bandwidth of the presentation channel.
Static: The available transmit bandwidth is assigned to each video channel, even if it is not
active.
Conference 1 VideoBandwidth Mode: Dynamic
The available transmit video bandwidth is distributed on the main channel and presentation
channel according to "MainChannel Weight" and "PresentationChannel Weight". If the main
channel weight is 2 and the presentation channel weight is 1, then the main channel will use
twice as much bandwidth as the presentation channel.
ADMIN
<1..10>
Range: 1 to 10.
Conference 1 VideoBandwidth MainChannel Weight: 5
The available transmit video bandwidth is distributed on the main channel and presentation
channel according to "MainChannel Weight" and "PresentationChannel Weight". If the main
channel weight is 2 and the presentation channel weight is 1, then the main channel will use
twice as much bandwidth as the presentation channel.
ADMIN
<1..10>
Range: 1 to 10.
Conference 1 VideoBandwidth PresentationChannel Weight: 5
Set the packetloss resilience mode. This configuration will only take effect for calls initiated after
the configuration is set.
ADMIN
<On/Off>
On: Enable the packetloss resilience.
Off: Disable the packetloss resilience.
Conference 1 PacketLossResilience Mode: On
Control how the presentation service is to be performed.
ADMIN
<LocalRemote/LocalOnly>
LocalRemote: The presentation will be shown locally and sent to remote side.
LocalOnly: The presentation will only be shown locally.
Conference 1 Presentation Policy: LocalRemote
Set the incoming Multisite call mode. The MultiSite feature allows participants from more than
two locations to join a meeting — by video and/or telephone.
ADMIN
<Allow/Deny>
Allow: Accept incoming calls to an already active call/conference. The incoming call will be
added to the MCU conference.
Deny: The system will not accept incoming calls when you are in a call. The calling side will
receive a busy signal.
Conference 1 IncomingMultisiteCall Mode: Allow
