Cisco UCS S3260 Storage Server Chassis Installation and Service Guide
Chapter 1 Overview
System Features Overview
System Features Overview
Table 1-1 lists the features of the system.
.
Table 1-1 Cisco UCS S3260 System Features
Chassis Four rack-unit (4RU) chassis.
Processors
• C3X60 M3 server nodes: Two Intel Xeon E5-2600 v2 Series processors inside
each server node.
• C3X60 M4 server nodes: Two Intel Xeon E5-2600 v4 Series processors inside
each server node.
• S3260 M5 server nodes: Two CPUs from the Intel Xeon Processor Scalable
Family. This includes CPUs from the following series:
–
Intel Xeon Silver 4XXX Processors
–
Intel Xeon Gold 5XXX and 6XXX Processors
Memory Up to 14 DIMMs inside each server node.
Multi-bit error
protection
This system supports multi-bit error protection.
Storage The system has the following storage options:
• Up to 56 top-loading 3.5-inch hard drives
• Up to four 3.5-inch rear-loading hard drives in an optional disk expansion tray.
• Up to four 2.5-inch, rear-loading SATA solid state drives (SSDs)
• M4 server node: one 2.5-inch, NVMe SSD inside each server node;
M5 server node: two 2.5-inch, NVMe SSDs inside each server node.
• Version 03 SIOC only: two 2.5-inch NVMe SSDs inside each SIOC.
Disk
Management
The system supports up to two storage controllers:
• One dedicated mezzanine-style socket for a Cisco storage controller card
inside each server node
• One dedicated mezzanine-style socket for a Cisco 12G modular storage
controller inside the optional I/O expander (when used with C3X60 M4 server
nodes)
Note The storage controllers that are supported in the S3260 M5 server node are
not supported in the I/O expander.
RAID Backup The supercap battery backup mounts to the RAID controller card.
The dual RAID controller used in M5 server nodes uses two supercap units.
PCIe I/O
• The optional I/O expander provides two 8x Gen 3 PCIe expansion slots.
• Version 03 SIOC only: one 8x Gen 3 PCIe expansion slot.
