• 1 stop bit

• No flow control

Connecting an Auxiliary Port to a Modem

To connect a modem to the voice gateway, follow these steps:

Before you begin

When a modem is connected to the auxiliary port, a remote user can dial in to Cisco VG310 or Cisco VG320

and configure it. Use the console cable and the DB-9-to-DB-25 connector adapter that comes with the accessory

kit.

For information on cabling, see Cable Specifications and Information.

Procedure

Step 1 Connect the RJ-45 end of the adapter cable to the AUX port on the voice gateway.

Step 2 Connect the other end of the cable to the connector on the modem.

See the figure in LAN and Power Cables, on page 12.

Connecting a Gigabit Ethernet Port to a Gigabit Ethernet Switch

Procedure

Step 1 Connect the cable from a Gigabit Ethernet port to an available port on the Gigabit Ethernet switch.

Step 2 If required, connect the second cable.

Ports and Cabling

The following table summarizes typical WAN, LAN, and voice connections for your Cisco VG310 or Cisco

VG320 voice gateway. For more information on cabling, see Cable Specifications and Information.

Table 5: WAN, LAN, and Voice Connections

CableConnectionPort Type, ColorPort or Connection

Category 5 or higher

Ethernet

Ethernet hub or Ethernet

switch

RJ-45, yellowEthernet

Installing the Cisco VG310 and Cisco VG320 Voice Gateways

Connecting an Auxiliary Port to a Modem
