Procedure
Step 1
Choose the sleeve size of the power cord retainer based on the thickness of the cord. The smaller sleeve can
be snapped off and used for thin cords.
Step 2
Slide the retainer around the AC power cord, and pass it around the loop on the switch.
Figure 14: Inserting the Retainer Through the Lanced Loop
Sleeve for thinner power cords3AC power cord1
Loop4Power cord retainer2
Step 3
Slide the retainer through the first latch.
Figure 15: Sliding the Retainer Through the Latch
Latch3AC power cord1
Cisco Catalyst 2960-L Series 24-Port and 48-Port Switch Hardware Installation Guide
26
Switch Installation
Installing the Power Cord Retainer (Optional)
