Smaller sleeve for thin power cords2
Step 4
Slide the retainer through the other latches to lock it.
Figure 16: Locking the Retainer
Latches3AC power cord1
Sleeve for thin power cords2
Step 5
(Optional) Use the small sleeve for thin power cords. Use the small sleeve to provide greater stability for thin
cords. Detach the sleeve, and slide it over the power cord.
Figure 17: Sleeve Around the Power Cord
AC power cord2Sleeve for thin power cords1
Cisco Catalyst 2960-L Series 24-Port and 48-Port Switch Hardware Installation Guide
27
Switch Installation
Installing the Power Cord Retainer (Optional)
