Citizen CMP-20 Technical Manual

CMP-30 product specification document
10
2.5 Battery specifications
1)
Battery type:
Lithium-ion rechargeable battery pack (2S1P)
2)
Individual batteries:
BK103450AR (B&K)
3)
Battery pack model name:
LK-PB20
4)
Battery capacity:
1800 mAh
5)
Nominal voltage:
7.4 V
6)
Discharge cut-off voltage:
6.0 V
7)
Charged voltage:
8.4 V
8)
Internal resistance:
350 mΩ or less
9)
Cycle life capacity:
70% or greater (after 300 standard charges and discharges)
10)
Dimensions:
59.6 (L) x 79.2 (W) x 14 (H) mm not including the projection
11)
Weight:
200 g or less
12)
Operating temperature:
0°C-45°C (standard charge), -20°C-60°C (standard discharge)
0°C-40°C (maximum discharge)
13)
Storage temperature:
-20°C-20°C (up to 1 year), -20°C-40°C(up to 3 months)
-20°C-60°C(up to 1 month)
14)
Storage humidity:
65% RH (without condensation)
2.6 Sensors
No-paper sensor, head temperature detection, battery charge level detection
2.7 Equipped memory capacity
1) Flash memory: 16 MB
2) SRAM: 4 MB
2.8 Magnetic stripe reader equipped (on equipped models)
Compatible cards: ISO/IEC 7811/7812 (JIS I format)
Card thickness: 0.76 mm ± 0.08 mm
Supported tracks: Tracks 1 & 2
Track reading width: 1.5 mm
Card slide speed: 10 cm - 15 cm/sec
Magnetic head life: 300,000 or more passes
Power consumption: Standard 3 mA (Dual), operating 500-900 uA (Dual)
Track
ISO-1
ISO-2
Bit density
210BPI
75BPI
Storage
capacity
79 characters
(7-bit)
40 characters
(5-bit)
