4.3 USB interface
Format: USB 2.0 Full Speed
Connector: USB mini B connector
Pin
number
Signal Details
1 +5V +5V
2 DATA- Receives data
3 DATA+ Receives data
4 GND Ground
Vendor ID: 0x0525
Product ID: 0xA702
Serial Number: 0x00
4.4 Bluetooth interface (Bluetooth compatible models)
Interface: Bluetooth standard 2.0 conformant
Frequency: 2402-2480 MHz
Channel spacing: 1 MHz
Number of channels: 79
Output class: Class 2
Modulation method: FH method (frequency hopping spectrum method)
Transmission distance: Approx. 10 m
Max. transmission speed: 115200 bps (Bluetooth and printer unit transmission speed)
Transmission ability: +4 dBm or less (Class 2)
Password: None
Support profiles: SPP and iAP (*1)
Passkey: Default value 0000 (multi-pairing compatible)
Local name: Default value “Mobile Printer”
With serial or USB connection, the passkey and discover blue mode can be changed via Utilities.
*1: The iAP profile requires firmware version 2.01A or later as well as hardware manufactured after
August 2013. The local name can also be changed under these same conditions.
SPP and iAP are automatically selected based on the connection.
Compared with SPP, the iAP signal speed is significantly slower.
